    Skiff Workshop Cage Bearings - Pivot: 3/16" - Ceramic Bearings: 1/16" - 12 ball

    Thumbnail Filmstrip of Skiff Workshop Cage Bearings - Pivot: 3/16" - Ceramic Bearings: 1/16" - 12 ball Images

      Purchase Skiff Workshop Cage Bearings - Pivot: 3/16" - Ceramic Bearings: 1/16" - 12 ball

      Skiff Workshop Cage Bearings - Pivot: 3/16" - Ceramic Bearings: 1/16" - 12 ball

      Manufacturer SKU: AC-SKF-6-316-12-116

      $14.00

      8 available for purchase

      Skiff Workshop Cage Bearings - Pivot: 3/16" - Ceramic Bearings: 1/16" - 12 ball

      These cage bearings are compatible with knives like the Pro-Tech Malibu, Mordax and McNees Mac 2, Spyderco Almagam and Smock, as well as the ZT 0450 and 0762. Click Compatibility tab for more info.

      PLEASE NOTE: Modifying your knife may void the OEM warranty on your knife. Please check the manufacturer's warranty for the knife that you will be modifying. By purchasing these cage bearings, you acknowledge this possibility, and that LynchNW or SKiff Workshop are not liable for any damage to your folding knife that may occur during installation of these bearings.

      Cage bearings that allow more balls to be placed around the knife pivot than standard cage bearings. Which provides more support for the blade and decreasing stress on each ball. The ceramic balls are captured in the disc but are still free floating to prevent binding.

      Includes Grade 5 ceramic bearings pre-installed.

      • 22% increased blade support over caged bearings of same size
      • Improved ball pathing around pivot
      • Less pivot screw tightening required
      • CNC machined from solid phosphor bronze

      Dimensions

      Inner Diameter
      Outer Diameter
      Thickness Ball
      0.189" 0.370" 0.050" 0.0625
      4.8mm 9.398mm 1.27mm 1.587mm












      Ordering details

      • One set equals two individual cage bearings


      Specifications

      Additional Installation and Maintenance Info from Skiff Workshop:

      The amount of torque needed for each knife's pivot when installing these bearings  is entirely by feel. You should start off lightly and test the blade, then tighten a little more, retest the blade. Repeat that until you are happy with the action. If you are using the 8mm x 1/16" bearings then you would need less torque when tightening the pivot since there are more balls to spread the load.

      For cleaning, you can use some light ammonia free de-greaser. Simple Green or even Windex should be fine. If you use a de-greaser then you should apply a drop of oil to each cage when installing. You can use compressed air to clean out the bearings. If the compressed air is too strong you may need to push some of the balls back to center if they become stuck on one side.

      Compatibility

      Bearing Compatibility

      The below knives have been found to work with this bearing.

      Click here to view the full Skiff Workshop compatibility chart.

      Alliance Designs
      • CMF Conquest
      Brian Brown (BBK)
      • Corvus
      • Raptor V2
      Brown Knives
      • FSD
      • Mini FSD
      Chaves
      • RCK9
      • Redencion 229
      • Redencion Street
      • Scapegoat
      Christensen Knifeworks
      • Maverick S (Reate)
      Civivi
      • Thug
      Divo
      • Growler (US)
      Ferrum Forge (Drop)
      • Mordax
      Flytanium
      • Talisong z
      Graham Knives
      • GMT Razel
      Hinderer
      • Firetac Triway*
      Kershaw
      • Bareknuckle
      • Lucha
      Koenig
      • Arius
      • Mini Arius
      • Mini Goblin
      Luft Concepts
      • RWB
      McNees
      • Mac 2 3"
      • Mac 2 3.5"
      Medford
      • Slim Midi
      North Arms
      • Skaha II
      Pena
      • X Series Alacran
      • X Series Mini Diesel
      Pro-Tech
      • Malibu
      • Mordax
      Schenk Knives
      • Ally
      Sharp by Design
      • Mini Evo
      • Mini Tempest
      • Typhoon EVO (Production)
      Spyderco
      • Amalgam
      • Paysan
      • Silverax
      • Smock
      Tactile Knife
      • Chupacabra
      • Mariner II
      • Rockwall (Thumbstud only)
      Trevor Burger
      • EXK
      • LEXK CFL
      • Urban
      • Urban XL
      Vero Engineering
      • Lux
      WE
      • Thug (2.69")
      Zero Tolerance (ZT)
      • 0055
      • 0450
      • 0450 (Ti)
      • 0456
      • 0460
      • 0470
      • 0762
      • 0804CF
      • 0808
